FE4P16Q

Four-wheels electric forklift 1,6 T - low centre distance 500 mm - Q Series

Compared with the N Series, the Q Series FE4P16Q 4-wheel electric forklift is much more compact, and therefore more suitable for working in confined areas. Q-series electric forklifts have also been developed with moderate applications in mind, with great comfort and efficiency. The FE4P16Q electric forklift moves and lifts loads of up to 1.6 tonnes.

more information
Designation Stock / EXW price per unit excl. VAT
FE4P16Q
Four-wheels electric forklift 1,6 T - Q Series

The configurations available for this model will appear below. If no configuration is available in stock, you can use the configurator and send us your request by email.
DESCRIPTION
TECHNICAL CHARACTERISTICS

  • FE4P16Q electric forklift load capacity: 1,6T
  • Drive: electric
  • Battery: Lithium or Lead-acid
  • Wheels: 4 solid rubber pneumatics
  • Weight (including battery) : 2940 kg
  • Mast light height: from 2500 mm to 5000 mm (consult mast table for capacity and mast specifications)
  • For mast lift heights, wheels specifications and overall dimensions, please consult the technical attribute tables.
  • The design of the electric forklifts Q series is based on the original Noblelift E series and N series with combination of the advantages to meet the light and medium applications with great comfort and efficieny. The truck is optional to equipped with either Lead-acid battery or Li-ion battery. With lowered center of gravity and overhead guard, the truck is ideal to be used in limited spaces such as entering elevator.
  • AC MAINTENANCE-FREE DRIVE MOTOR: Adopt maintenance-free and powerful AC drive motor. Compared with traditional DC motors, Noblelift' s AC motors do not need to replace Carbon brushes. Equipped With speed sensor and temperature sensor, greatly improving the AC motor' s reliability.
  • SIDE- EXTRACTION BATTERY: Battery can be replaced easily by using another forklift, meeting continuous application if necessary.
  • LOW CENTER OF GRAVITY: Transmission system uses a horizontal fan-shaped drive Axle arranged in parallel and has a large transmission ratio. The battery is installed at the bottom of the frame, vehicle height is 2080mm with easy entrance to limited doors and high stability.
  • QUIET LOW VIBRATION DESIGN: The hydraulic system uses a low-noise gear pump and full hydraulic power steering. Quiet and comfortable operation. Shock absorbing steer axle to protect the vehicle system and prolong the service life of the forklift.
  • SAFER AND EASIER ELECTROMAGENTIC BRAKE: Adopts car control mode and electromagnetic braking to make the driver's operation more comfortable.
  • The vehicle hood and the left and right small side- panels are formed by steel plates at one time, which is simple and decent and more convenient to operate.
  • The forklift is equipped with standard LED lamps: head­lamps, front turn lamps, rear combination lamps, warning lamps. Bright light with low power consumption allows you to operate freely at night.
  • Compared with other N series 4-wheel Electric counter balance forklift, this model is smaller in size and more flexible, which is more suitable for working in confined areas.
  • Intelligent buffering when descending to the ground, effectively protecting the ground and cargo from damage.
  • Transmission system uses a horizontal fan-shaped drive axle arranged in parallel with a large transmission ratio. The battery is installed at the bottom of the frame. Traveling motor a do pts AC mainte­nance-free motor.
  • Multi-function display screen with fault alarm, low battery reminder. High, medium and low speed modes.
  • Steer axle shock absorption designed to protect the vehicle and pro long the service life of the truck.
  • Front multi-way valve operating device makes operation more comfortable.
  • Electromagnetic brake button eut off power at one time, making brake safer and easier.
  • Ergonomie hydraulic controls for comfort operation with wide mast view and easy right-sided control levers and steering wheel with knob.
  • The trucks are equipped with Curtis controllers, CAN-bus technology makes the diagnostic and troubleshooting easier.
  • The use of proved and certified components helps to ensure the conformity to international safety standards with ail the supporting documents available as required by law.
  • Each battery can be diagnosed via CAN connection with help of special software tool, the software can provide information about the battery condition such as balance of cells, a mou nt of charging/dis­charging cycles, current, energy consump­tion, temperature, charging/discharging parameters, voltage of every cell, faults and alarms, settings of timing for automatic turn off.

Options

  • It is optional to equipe the forklift with Lithium battery with the advantage of maintenance-free and fast charging, no headaches for en users esp. Light-duty/occasionnal applications. Lead-acid and lithium batteries are perfectly internchageable. Do not worry about wich battery to choose now.
