FE4P35GH

Double drive 4-wheel lithium electric forklift truck - Top-of-the-range - 3.5T

FE4P35GH

Double drive 4-wheel lithium electric forklift truck - Top-of-the-range - 3.5T

The FE4P35GH dual-motor 4-wheel lithium electric forklift truck is a top-of-the-range model with a load capacity of 3.5 tonnes. Backed by more than two decades of expertise, this truck rivals internal combustion models thanks to its exceptional robustness, power and reliability, while offering a more environmentally-friendly and cost-effective solution.

more information

	Designation	Stock / EXW price per unit excl. VAT
	FE4P35GH Electric forklift double drive 2WD 3,5 T The configurations available for this model will appear below. If no configuration is available in stock, you can use the configurator and send us your request by email.

DESCRIPTION

TECHNICAL CHARACTERISTICS

NOBLELIFT's G series of lithium-electric forklifts comes in two versions: the top-of-the-range GH models (FE4P30GH and FE4P35GH) and the standard GB models (FE4P30GB and FE4P35GB).
Ruggedness and compact design: GH series 4-wheel forklift trucks combine an innovative, compact structure with an elegant, robust appearance for excellent manoeuvrability even in tight spaces. This design, inspired by the Q series, is ideal for demanding industrial environments and offers a high quality product at a competitive price.
Fast, efficient loading: The FE4P35GH lithium forklift uses an AC system to ensure optimum performance and superior energy efficiency. This truck offers an efficient alternative to traditional models with reduced charging times. The rapid battery charging system maximises uptime and meets the demands of a variety of working conditions.
Workstation comfort: The FE4P35GH forklift is ergonomically designed. It is designed for maximum operator comfort. The wide visibility of the mast ensures increased safety, while the spacious workspace and ergonomic design help to reduce fatigue. The intelligent, intuitive dashboard with graphic interface makes it easy to change gear modes and use the truck as a whole. This makes operations simpler and more efficient.
Efficiency and practicality: The FE4P35GH twin-motor forklift offers a variety of lithium battery capacities to meet different operational needs. The side-pull structure allows batteries to be replaced quickly, ensuring continuous operation 24 hours a day. Equipped with maintenance-free asynchronous AC motors, this truck offers improved working efficiency and reduced maintenance costs. What's more, the driver's seat has a USB port for added comfort and convenience.
Safety and intelligent management: The intelligent lithium management platform constantly monitors the state of the battery, ensuring the safety of personnel and equipment. By scanning the QR code on the battery, users can easily access usage and charge data. The top-of-the-range GH series forklift also features OPS as standard and full LED lighting for optimum visibility and enhanced safety.

Technical specifications of the FE4P35GH 4-wheel lithium forklift truck:

Load capacity and centre of gravity:
Load capacity/rated load: 3500 kg
Centre of gravity: 500 mm
Load distance between centre of drive axle and fork: 483 mm

Mast type and lift height:
Mast tilt: 6/10 °
Mast height retracted: 2185 mm
Free lift: 145 mm
Basic lift height: 3000 mm
Mast height extended: 4079 mm

Power source:
Transmission: Electric
Standard battery: Lithium
Battery voltage, K5 rated capacity: 76.8/206 (277/412/460/554 optional) V/Ah
Battery weight: 947 kg

Tyre type and dimensions:
Tyre type: PPS
Tyre size front: 28x9-15-14PR
Tyre size rear: 6.50-10-10PR
Number of wheels front/rear (x = drive wheels): 2x/2

Overall dimensions:
Wheelbase: 1700 mm
Running weight with battery: 4170 kg
Front track width: 1004 mm
Rear track width: 982 mm
Height of protective roof (cab): 2200 mm
Total length: 3688 mm
Length to front of forks: 2618 mm
Total width: 1230 mm
Fork dimensions: 45/125/1070 mm

Speed and performance:
Travel speed, with load/unloaded: 17/19 km/h
Lifting speed, with load/unloaded: 0.42/0.56 m/s
Lowering speed, with load/unloaded: <0.6 m/s
Traction, with load/unloaded S2 60 min: 20000/21000 N
Maximum performance on gradients, with load/unloaded S2 5 min: 20/25 %.

Ergonomics and operator comfort:
Ergonomic seat with USB port: Comfort and convenience
Widescreen mast design: Safety and comfort
OPS system as standard: Operator safety
Intelligent instrument panel with graphical user interface: Enhanced user experience

Safety systems and energy efficiency:
LED lighting: headlights, auxiliary lights, rear combination lights, hazard lights
AC induction motors: efficiency and reduced maintenance
Intelligent lithium management platform: continuous battery monitoring
Service brake: hydraulic

A few examples of application areas and solutions provided by the FE4P30GH electric forklift truck

Logistics and warehousing
Problems encountered by operators: Manoeuvrability in confined spaces, need to move quickly and safely.
Solution provided by the FE4P30GH lithium forklift: The compact design and tight turning radius of this powerful compact forklift provide excellent manoeuvrability. With a travel speed of 15 km/h, it enables fast, efficient operations. The wide visibility of the mast and the ergonomic design of the workstation ensure optimum operator safety.

Manufacturing industry
Problems encountered by operators: Handling heavy loads, intensive work cycles.
Solution provided by the FE4P30GH lithium forklift truck: With a load capacity of 3,000 kg, the 3-tonne electric forklift truck is ideally suited to the needs of the manufacturing industry. Maintenance-free asynchronous motors and a robust structure ensure reliable performance even in the most demanding working conditions.

Distribution and retail
Problems: Need for speed and flexibility in loading and unloading.
Solutions: The fast loading system of the fast loading forklift maximises the efficiency of loading and unloading operations. Different lithium battery capacities and easy battery replacement ensure flexibility and continuity of service.
